Machine Documentation

Douglas provides informative and easy to understand Operator and Service machine documentation. Optional job aids simplify daily operator and service procedures and help language barriers.

Standard Documentation Packages

  • Two operator manuals (provided at machine shipment)
  • One set of vendor supplied OEM bulletins (provided at machine shipment)
  • Two service manuals (provided 10 to 14 days after machine shipment)
  • One USB flash drive containing (provided 10 to 14 days after machine shipment):
    • Operator Manual (.pdf format)
    • Service Manual (.pdf format)
    • Bill of Materials (.xls format)
    • Original Changeover settings (.xls format)
    • Original Recipe Variable Settings (,xls format)
    • Assembly drawings (.pdf format)
    • Electrical drawings (.pdf and .dwg format)
    • Electrical program & HMI program (PLC program)
  • Two sets of job aids (printed and electronic – .pdf only) (provided 10 to 14 days after machine shipment):
    • Changeover Settings Table
    • Changeover Quick Reference Guide Handbook
    • Troubleshooting Quick Reference Guide Handbook

For complete program details, please contact Technical Support
